Zero Temperature Coefficient (ZTC) Current Limiting Diodes

Zero Temperature Coefficient (ZTC) Current Limiting Diodes

regulator current 27.5mA - 575mA | maximum limiting voltage 1.5V - 2.0V


Central Semiconductor’s CDCLD series Zero Temperature Coefficient (ZTC) Current Limiting Diodes (ZTC CLDs) are specifically intended for applications requiring constant current regulation, and were designed with a unique process which maintains constant current over a broad temperature range. This Zero Temperature Coefficient feature eliminates the need for additional resistors to compensate for variation in the current limit as a result of changes in temperature. The regulator current values range from 27.5mA to 575mA with a maximum limiting voltage (VL) from 1.5V to 2.0V.

Manufactured in the industry standard DPAK surface mount package, these Industry First devices are ideal for high intensity industrial and consumer lighting systems, as well as test/measurement equipment and standard LED applications.

Device specifications and curves may be found on the product brief and datasheet.


Explore the performance characteristic differences between MOSFET-based CLDs and traditional JFET CLDs.

Click below to download:


  • Constant current range
  • Temperature independance
  • High stability over wide temperature range
  • Nominal current regulation at low voltage input
  • Available in bare die


  • Eliminates need for additional resistors
  • Active current source performance
  • Optimized for heat disspiation

also available at:

ideal applications:

LED lighting
test & measurement equipment
light dimming systems
infrastructure lighting
high intensity lighting systems
